Specifications
ROHS approved Li-SOCL2 ER26500 battery
1.UL&CE&ISO9001&SGS&UN38.3 certified
2. 3.6V 9.0Ah C size
3.10year shelf life
ROHS approved Li-SOCL2 ER26500 battery
Model | Size | Noninal Voltage(V) | Termination Voltage(V) | Noninal Capacity(mAh) | Max. current(mA)
| Maximum Dimension | Weight(g) | Workable temp. | ||
Constant
| pulse | Diameter (mm)
| Height (mm)
| |||||||
ER26500 | C | 3.6 | 2.0 | 9000 | 200 | 400 | 26.2 | 50.5 | 55 | -55°C-85°C |
Applications:
1. Memory backup: CMOS memory, RTC(real time clock) and computer backup.
2. AMR utility meters: Electricity meter, gas meter and water meter etc.
3. Wireless alarm sensors: Smoke alarm systems, temperature monitors etc.
4. Remote monitor systems: GPS, sea buoys, lifejacket lights, lifecraft lights, cargo-locating systems etc.
5. Automotive and electronics: Automotive security systems, tire-pressure monitoring systems etc.
6. Electronics toll tags: Toll gates
7. Military electronics: Radio communication, night vision equipment, tracking and positioning systems etc.
Advantages:
1. High energy density
2. High open circuit voltage
3. Wide range of operating temperature
4. Stable operating voltage and current
5. Long operating time
6. Low self-discharge rate (less than 1% per year at 25°C).
Specifications
