HIGH SPEED, HIGH PRECISION, HIGH POWER, LARGE MARKING AREA!
It adopts Coherent or Rofin CO2 laser source from America with stable laser output, high quality laser beam,
long service time and high precision. Compared with normal marking system, it has higher speed and better
beam facula. It works so best in leather cutting and marking industry.
Machine Characteristics
Advanced machine technology, simple operation, with high-speed marking vibration lens, photoelectric conversion efficiency of high marking speed, the effect is not deformed and meticulous precision, full-enclosed Optical system design, the failure rate is low, maintenance-free, low processing costs can be for 24 hours of working.
Portable 10W 30W CO2 laser marking machine Parameters
Model | WLD-10L-III | WLD-30L-III |
Laser Wavelength | 10.64μm | |
Laser Power | 10W | 30W |
Laser source | Import 10W America Coherent metal laser tube | |
Pulse frequency | ≤20kHz | |
Marking Area | 70mm×70mm 110mm×110mm 160mm×160mm 300mm×300mm | |
Marking Depth | ≤0.5mm(Determined by material) | |
Marking Speed | ≤7000mm/s | |
Min linear width | 0.15mm | |
Minimum Character | 0.4mm | |
Repeat Positioning Accuracy | ±0.01mm | |
Power Supply | AC220V/50Hz(Customized) | |
Cooling Way | Circulation of Water Cooling | |
File Formats | PLT, DXP, BMP, JPG etc | |
Output Compatibility | AutoCAD, Photoshop, CorelDRAW etc | |
Rated Power Consumption | 350W | |
Application
Applications Materials
Non-metal Material such as leather, cloth, textile, rubber plate, wood, bamboo products, acrylic plate, plastic, organic glass, tile, marble,jade, crystal, shell, and all kinds of nonmetallic materials.
Applications Fileds
Material: Non-metal materials such as leather, cloth, wood, acrylic, ABS, paper, acrylic etc.
Field: Glass industry, package industry, sign industry, leather products industry, wood industry etc
