Geared Motor with gearbox and speed controller

Brand:

Price:

a Set of

25.50

1 - 9 a Set of

23.50

10 - 49 a Set of

21.80

50 + a Set of

< >

Color:

Size:

Quantity:

- + a Set of

Total Price:

Depends on the product properties you select

Inquire Now

< >

The Motor Specification:

Voltage:DC 24V
Reduction Ratio:1/227
Gearbox Length:29.5 mm
No-Loard Speed:20 Rpm
Rated Speed:14 Rpm
Rated Torque:15 Kg.cm
Rated Current:0.92A

Net weight:0.25 KG

Speed Controller Specification:

1, Input voltage requirements: 10V-36V DC

2, the maximum output power: 150W

3, the maximum continuous current 5A, overload and short circuit protection current 8A, short-circuiting time is not more than 30 seconds

4, PWM pulse width modulation range: 0% -100%

5.Net Weight:0.06 KG

6.Size:73.5*45.5*27mm,Positioning hole diameter 3.5mm

DC 24V Mini Geared Motor with gearbox and speed controller especial for Robot
